ThunderHex Bushings
Bushings are great for many low speed or high load FRC applications. Since they’re smaller and lighter than bearings, you can save weight and size while still using any ThunderHex shaft. Our ThunderHex Bushings come in two sizes: 10.25mm for 3/8" ThunderHex and 13.75mm for 1/2” ThunderHex. The acetal plastic bushings are great for low load applications and the oil impregnated bronze bushings are great for high load applications.
217-7345
(10) 10.25mm (3/8 ThunderHex) ID x 0.625" OD x 0.313" WD (Plastic Flanged Bushing)
217-7346
(6) 10.25mm (3/8' ThunderHex) ID x 0.625' OD x 0.313' WD (Bronze Flanged Bushing)
217-7347
(10) 13.75mm (1/2" ThunderHex) ID x 0.625" OD x 0.313" WD (Plastic Flanged Bushing)
217-7348
(6)13.75mm (1/2" ThunderHex) ID x 0.625" OD x 0.313" WD (Bronze Flanged Bushing)
217-7345 / 217-7347
Acetal
217-7346 / 217-7348
Oil Impregnated Bronze
0.004lbs each
-
CAD
-
10.25mm (3/8" ThunderHex) ID x 0.62" OD x 0.313" WD (Plastic Flanged Bushing) (217-7345)
-
13.75mm (1/2" ThunderHex) ID x 0.625" OD x 0.313" WD (Plastic Flanged Bushing) (217-7347)
-
13.75mm (1/2" ThunderHex) ID x 0.625" OD x 0.313" WD (Bronze Flanged Bushing) (217-7348)
-
10.25mm (3/8" ThunderHex) ID x 0.625" OD x 0.313" WD (Bronze Flanged Bushing) (217-7346)
