Wheels

As low as $0.00
In stock
Compatible with products and accessories.
VRC, VEX U, VAIC legal.

Defense may not always win championships, but being able to move does. Put some power on the floor with our large variety of wheel options available for builders.

Omni-Directional or Mecanum Wheels are great for quick, lateral movements. If you need more grip, Traction Wheels offer great pushing ability and are designed for optimal grip on soft surfaces like the foam tiles used in the VEX Robotics Competition.

  • Offered in multiple sizes
  • Wheel diversity allows for numerous applications
Omni-Directional Wheels
Traction Wheels
Mecanum Wheels
Other
Wheel Type Wheel Size Wheel SKU Configure
Omni Directional Wheels 2.75" 2.75" Omni-Directional Wheel - Double Roller (2-pack) 276-1902 Select
3.25" 3.25" Omni-Directional Wheel (4-Pack) 276-3526 Select
4" 4" Omni-Directional Wheel (2-pack) 276-2185 Select
Traction Wheels 2.75" 2.75" Wheel (4-pack) 276-1496 Select
3.25" 3.25" Traction Wheel (4-Pack) 276-3525 Select
4" 4" Wheel (4-pack) 276-1497 Select
5" 5" Wheel (4-pack) 276-1498 Discontinued
Mecanum Wheels 2" 2" Mecanum Wheel (4-Pack) 217-7400 Select
4" 4" Mecanum Wheel 276-1447 Select
Other N/A Wheel Kit 276-2164 Select
N/A 4" High Traction Tire 276-1489 Select
N/A 6" Wheel Leg 276-2218 Discontinued





Wheel Kit (276-2164)

2.75" Double-Roller Omni-Directional Wheels (276-1902)

  • (2) 2.75" Double-Roller Omni-Directional Wheels

3.25" Omni-Directional Wheels (276-3526)

  • (4) 3.25" Omni-Directional Wheels
  • (8) Metal Shaft Inserts
  • (8) Plastic Shaft Inserts

4" Omni-Directional Wheels (276-2185)

  • (2) 4" Omni-Directional Wheels

2.75" Diameter Wheels (276-1496)

  • (4) 2.75" Diameter Wheels

3.25" Traction Wheel (276-3525)

  • (4) 3.25" Traction Wheel
  • (8) Metal Shaft Inserts
  • (8) Plastic Shaft Inserts

4" Diameter Wheels (276-1497)

  • (4) 4" Diameter Wheels

5" Diameter Wheels (276-1498)

  • (4) 5" Diameter Wheels

4" High Traction Tire (276-1489)

  • (4) 4" High Traction Tires (Note: Wheel rims not included.)

2" Mecanum Wheel (217-7400)

  • (2) 2" Mecanum Wheel - Left
  • (2) 2" Mecanum Wheel - Right

4" Mecanum Wheel (276-1447)

  • (2) 4" Mecanum Wheel - Left
  • (2) 4" Mecanum Wheel - Right

Plastic 1/2" VersaHex Adapters v2 (1/4" Square Bore) (16 Pack) [217-8004]

  • (8)  Plastic 1/4" Square to 1/2" Hex Adapter, 1/8" Long
  • (8)  Plastic 1/4" Square to 1/2" Hex Adapter, 1/4" Long

6" Wheel Legs (276-2218)

  • (4) 6" Wheel Legs

Omni-Directional Wheels

  • 2.75" Double-Roller Omni-Directional Wheels: 0.154 lbs (70 grams)
  • 3.25" Omni-Directional Wheels: 0.132 lbs (60 grams)
  • 4" Omni-Directional Wheels: 0.232 lbs (105 grams)

Traction Wheels

  • 2.75" Wheels: 0.110 lbs (50 grams)
  • 3.25" Traction Wheels: 0.110 lbs (50 grams)
  • 4" Wheels: 0.198 lbs (90 grams)
  • 5" Wheels: 0.352 lbs (160 grams)

Traction Tires

  • 4" High Traction Tires: 0.077 lbs (35 grams)

Mecanum Wheels

  • 2" Mecanum Wheels: 0.122lbs (55.34 grams)
  • 4" Mecanum Wheels: 0.41 lbs (186 grams)

Wheel Legs

  • 6" Wheel Leg: 0.074 lbs (34 grams)


All listed weights are actual weights of one item (no packaging)



Click the  button next to a file to view it in your browser.

Omni-Directional Wheels

  • 2.75" Double-Roller and 4" Omni-Directional Wheels are compatible with 0.125" square bar drive shafts
  • 3.25" Omni-Directional Wheels are compatible with All VEX EDR shafts. (0.25" and 0.125" square bars)

Traction Wheels

  • 2.75", 4" and 5" Traction Wheels are compatible with 0.125" square bar drive shafts.
  • 3.25" Traction Wheels are compatible with All VEX EDR shafts. (0.25" and 0.125" square bars)

Traction Tires

  • Use with 4" VEX wheels

Mecanum Wheels

  • 2" Mecanum Wheels are compatible with High Strength (0.25") drive shafts, when also using VersaHex Adapters.
  • 4" Mecanum Wheels are compatible with 0.125"(3.2mm) square bar drive shafts

Wheel Legs

  • 6" Wheel Legs are compatible with 0.125"(3.2mm) square bar drive shafts.
